1D / Linear Codes

1D / LINEAR CODES Autodiscriminates all standard 1D codes including GS1 DataBar™ linear codes

2D CODES Aztec Code; China Han Xin Code; Data Matrix;MaxiCode; Micro QR Code; QR Code

POSTAL CODES Australian Post; British Post; Canadian Post; China Post; IMB; Japanese Post; KIX Post; Korea Post; Planet Code; Portuguese Post; Postnet; Royal Mail Code (RM4SCC); Swedish Post

STACKED CODES EAN/JAN Composites; GS1 DataBar Composites; GS1 DataBar Expanded Stacked; GS1 DataBar Stacked; GS1 DataBar Stacked Omnidirectional; MacroPDF; MicroPDF417; PDF417; UPC A/E Composites

Electricity:

CURRENT Operating (Maximum): 200 mA

Operating (Typical): 175 mA;

INPUT VOLTAGE 5 VDC +/- 5%

Environment::

AMBIENT LIGHT 0 to 100,000 lux

DROP RESISTANCE Withstands repeated drops from 1.2 m / 4.0 ft onto a concrete surface

ESD PROTECTION (AIR DISCHARGE) 16 kV

HUMIDITY (NON-CONDENSING) 90%

PARTICULATE AND WATER SEALING IP52

TEMPERATURE Operating: 0 to 40 °C / 32 to 104 °F

Storage/Transport: -40 to 70 °C / -40 to 158 °F

Interface::

INTERFACES RS-232; USB: OEM USB; USB COM; USB HID Keyboard

Physical characteristics

COLORS AVAILABLE Black; White

DIMENSIONS With Stand: 12.1 x 10.7 x 7.3 cm; Without Stand: 7.4 x 9.5 x 6.4 cm

WEIGHT With Stand: 295.0 g; Without Stand: 178.0 g / 6.3 oz

Reading performance:

LIGHT SOURCE Aiming: 650 nm VLD
Illumination: 625 nm LED

READING INDICATORS Beeper (Adjustable Tone and Volume); Datalogic ‘Green Spot’ Good Read Feedback; Good Read LED

RESOLUTION (MAXIMUM) 1D / Linear Codes: 0.102 mm / 4 mils
Data Matrix: 0.178 mm / 7 mils
